Crane Body

DOMINATOR® IV

With enhanced strength and stability for higher crane loads, numerous configuration possibilities, and a body rating of 95,000 ft-lb (13.3 tm), the Dominator IV mechanics truck offers exceptional performance in virtually any industry. With the Dominator IV mechanics truck, you don’t have to bring your equipment into the shop for service, because the shop comes to you.

Standard features:

  • Body rating — 95,000 ft-lb (13.3 tm)
  • Enhanced strength and stability for higher crane loads
  • Multiplex electrical system with programmable logic

Options:

  • LED Lighting
  • Drawers and drawer sets
  • Standard adjustable shelves
  • 3″H (7.6 cm) divided adjustable shelves
  • Manual and hydraulic stabilizers
  • Workbench vises and vise plates
  • Compartment pressurization system
  • Air systems
  • Telescopic cranes up to 95,000 ft-lb (13.3 tm)

Find a Distributor Request a Quote

ModelDominator IV (14')
Body Rating95,000 ft-lb
Body Weight5,758 lb
Body Width98 inches
Storage Capacity204 cu ft
Max. IMT Crane Model14000
ModelDominator IV (19')
Body Rating95,000 ft-lb
Body Weight7,279 lb
Body Width98 inches
Storage Capacity269 cu ft
Max. IMT Crane Model14000
*Body weight and storage capacity are estimated based on product configuration.

IMT Full Line Pocket Brochure
Download

DOM IV_Sidepack Dimensions
Download
